DIATEX offers a full range of filtration products for aquaculture.

The available fabrics have meshes from 21 to 2000 μ and are made of polyethylene (HDPE), nylon (PA) or polyester (PES), depending on the characteristics required.

DIATEX fabrics can be used to filter spirulina, to create fish farm enclosures, to prevent the intrusion of predators (crabs), and for oyster farming.
Available colours: Crystal.

NYLON 66 MONOFILAMENT FABRIC

Our fabrics offer very good mechanical, abrasion and alkali (salt) resistance.

Ref. Mesh
opening
(microns)		 Number of threads/cm x cm Free
surface
(%)		 Thread
Diam.(µm)		 Fabric
thickness
(µm)		 Weight
(g/m²)		 Width
(m)
PA12.50* 2000 4.3 – 750 – 500 1.60
PA12.50* 1800 4.5 61 500 950 205 1.31
PA16.40* 1320 6 56 400 820 170 1.31
PA20.35 1000 7.8 55 350 – 171 1.83
PA22.30 920 8.1 56 300 540 140 1.83
PA25.30 750 10 52 300 530 162 1.50
PA30.25* 600 11 – 250 – 135 1.83
PA43.18* 400 16 48 180 – 110 1.83
PA54.16* 300 20 43 160 – 101 1.83
PA62.14 300 22.7 46.5 140 270 96 1.65
PA73.12 250 27 47 120 210 80 1.25
PA84.10 200 30.9 48 100 170 72 1.50
PA97.10* 150 36 – 100 – 95 1.20
PA171.6* 100 63 – 60 – 49 1.82
PA165.6 100 61 41 60 105 44 1.55
PA208.5 80 77 43 50 85 42 1.55
PA267.44* 50 105 27 44 81 38 1.28
PA405.37* 31 150 21 37 68 40 1.14
PA420.37* 25 165 15 37 73 42 1.14
PA542.30* 21 200 17 30 65 34 1.14
032PES3-
4/114*		 32 34 20 34 60 40 1.14
